Demo_documentar_ai_Orca

Introduction

The Demo_documentar_Orca project implements an innovative solution to modernize and document legacy or extensive codebases in PowerBuilder. Using the native ORCA API to manipulate the library (PBL) and connecting to artificial intelligence models (LLMs) via Ollama, the system extracts the code, generates standard comments and headers, and automatically re-imports it in a validated manner.

General Flow Architecture (Infographic)

┌─────────────────────────────────────────────────────────────┐
│                 ENTORNO POWERBUILDER                        │
│                                                             │
│                   1. Crea Backup                            │
│                 ┌────────────────┐                          │
│                 ▼                │                          │
│  ┌────────────┐ │ 2. Exporta     ┌───────────────────┐      │
│  │   PBLs     ├─┴───────────────►│  nvo_orca         │      │
│  │(Originales)│◄─────────────────┤ (Controlador)     │      │
│  └────────────┘   5. Importa     └─────────┬─────────┘      │
│                                            │                │
└────────────────────────────────────────────┼────────────────┘
│
│ 3. Script
│    + Prompt
▼
┌─────────────────────────────────────────────────────────────┐
│                 CAPA DE INTELIGENCIA ARTIFICIAL             │
│                                                             │
│  ┌─────────────────────────┐         ┌───────────────────┐  │
│  │ w_doc_auto_headers_demo │◄────────┤ nvo_ai_utils      │  │
│  │ (Valida Firmas y Cierre)│ 4. JSON │ (Llama a Ollama)  │  │
│  └─────────────────────────┘         └───────────────────┘  │
└─────────────────────────────────────────────────────────────┘

Step-by-Step Process

Code Implementation (Scripts)

1. ORCA interaction to import and compile

The nvo_orca object exposes the of_importar_objeto function, which handles opening the ORCA session, injecting the updated source code back into the PBL, and closing the session:

// Fragmento de nvo_orca.sru
li_rc = of_abrir_sesion(lh_sesion, as_app_pbl, as_app_name, as_library_list, ls_mensaje)
if li_rc <> 0 then return li_rc

li_rc = of_leer_archivo(as_archivo_fuente, ls_codigo, ls_mensaje)
ll_bytes = of_len_bytes_unicode(ls_codigo)

// Función nativa de ORCA para importar y compilar
li_rc = PBORCA_CompileEntryImport(lh_sesion, as_pbl_destino, as_nombre_objeto, &
ai_tipo_orca, "Importado por nvo_orca", ls_codigo, ll_bytes, 0, 0)

if li_rc = 0 then
of_cerrar_sesion(lh_sesion)
return 1
end if

2. AI (Ollama) connection from PowerBuilder

The API invocation is performed using HTTPClient in PowerBuilder. The request JSON is strictly structured, escaping the source code to avoid syntax errors.

// Fragmento de nvo_orca.sru (of_corregir_codigo_con_ai)
httpclient lnvo_http
lnvo_http = create httpclient
lnvo_http.SetRequestHeader("Content-Type", "application/json")

ls_prompt = "Corrige este objeto PowerBuilder para que compile... " + &
"Error ORCA: " + as_error + "~r~nCódigo fuente:~r~n" + as_codigo

ls_json = '{"model":"' + of_json_escape(is_ai_model) + '","prompt":"' + of_json_escape(ls_prompt) + '","stream":false}'

li_rc = lnvo_http.SendRequest("POST", ls_url, ls_json)
lnvo_http.GetResponseBody(ls_response)
as_codigo_corregido = of_limpiar_codigo_ai(of_extraer_texto_ai(ls_response))

3. General AI Utilities (nvo_ai_utils)

The nvo_ai_utils object provides key tools like of_replace_all, which allows for iterative cleaning of line breaks or special characters before injecting or processing LLM responses.

// Fragmento de nvo_ai_utils.sru (of_replace_all)
String ls_result
Long ll_pos, ll_find_len

ls_result = as_source
ll_find_len = Len(as_find)
ll_pos = Pos(ls_result, as_find)

Do While ll_pos > 0
ls_result = Left(ls_result, ll_pos - 1) + as_replace + Mid(ls_result, ll_pos + ll_find_len)
ll_pos = Pos(ls_result, as_find, ll_pos + Len(as_replace))
Loop
Return ls_result

Key Model Benefits

• Zero Manual Touch: Documents hundreds of objects in batches without requiring copy and paste.
• Code Security: The validation barrier prevents AI hallucinations from breaking the application.
• Standardization: Ensures that all headers and comment languages maintain the same corporate structure (e.g., comments in Spanish, without problematic accents).

System Requirements & Prerequisites

To successfully run the ORCA automation and AI documentation processes, the following components must be installed:

• PowerBuilder IDE: Version 2019 R3, 2021, or 2022. The system requires the native PB ORCA compiler API. The corresponding ORCA DLL (e.g., pborc190.dll, pborc210.dll, or pborc220.dll) must be available in the system's PATH or the application's root directory.
• Ollama: Installed locally or accessible via network (Version 0.1.28 or newer recommended) to host the LLM engine.
• LLM Model: A downloaded model in Ollama (e.g., minimax-m3:cloud, etc.) for code analysis.
